Khan Engineering offers a 200 Kg/Hr Pasta Manufacturing Full Plant for medium to large-scale pasta production businesses in India. The plant is designed for continuous production, easy operation, uniform pasta shapes and efficient drying.

This complete pasta production setup includes the main pasta making machine along with essential equipment such as a screw conveyor, vacuum mixer, extruder, control panel, conveyor belt, cooling system, pasta dies, Italian inserts, wooden trays, trolleys and batch dryer.

With a production capacity of up to 200 kg per hour, this plant is suitable for manufacturers who want to produce different types of pasta commercially with consistent quality.

What is a 200 Kg/Hr Pasta Manufacturing Plant?

A 200 kg/hr pasta manufacturing plant is a commercial production line designed to convert pasta raw material into different pasta shapes through mixing, extrusion, shaping and drying.

The plant can produce approximately 200 kg of pasta per hour, depending on the raw material, pasta shape, recipe, operating conditions and final product requirements.

Khan Engineering provides a complete solution so that manufacturers can set up a professional pasta production unit without arranging every major machine separately.

Complete Pasta Manufacturing Process

The pasta manufacturing process starts with feeding the raw material into the production line.

1. Raw Material Feeding

Raw material is loaded into the screw conveyor, which transfers it to the processing section. This reduces manual material handling and helps maintain a smooth production flow.

2. Mixing

The raw material is mixed with the required quantity of water to prepare a uniform mixture. The mixing system helps achieve the right consistency before extrusion.

3. Vacuum Mixing

The vacuum mixing system helps prepare a more uniform pasta mixture and supports consistent extrusion and finished product quality.

4. Pasta Extrusion

The prepared mixture enters the pasta extruder. Pressure inside the extruder pushes the mixture through the selected pasta die.

This is where the pasta gets its required shape.

5. Pasta Shape Formation

Different dies and inserts can be used to manufacture different pasta shapes. Changing the die allows manufacturers to expand their product range using the same production plant.

6. Conveyor Transfer

Freshly extruded pasta falls onto the conveyor belt, where it is transferred for further handling and drying preparation.

7. Tray Loading

Fresh pasta is collected and spread on wooden trays. The trays are then arranged inside specially designed trolleys.

8. Batch Drying

The loaded trolleys are placed inside the batch pasta dryer.

The drying system removes moisture from fresh pasta under controlled conditions. Proper drying is an important stage because it helps improve pasta stability, storage life and final product quality.

After drying, the pasta is ready for cooling, packing and further processing as required.

Main Components of the 200 Kg/Hr Pasta Plant

The complete setup can include:

• Screw Conveyor – for easy and continuous raw material feeding.
• Vacuum Mixer – helps prepare a consistent pasta mixture.
• Pasta Extruder – forms pasta through the selected die.
• 3 Sets of Pasta Dies – useful for producing different pasta varieties.
• Italian Inserts – designed for accurate and consistent pasta shaping.
• Control Panel – provides centralized machine operation and control.
• Conveyor Belt – carries freshly produced pasta from the extrusion section.
• Cooling System / Cooling Tower – supports temperature control during production.
• Wooden Trays – used for arranging pasta during the drying process.
• Trolleys – designed to hold multiple trays for convenient movement.
• Batch Pasta Dryer – provides controlled drying of freshly produced pasta.

Machine configuration and supplied components can be customized according to production requirements.

Different Pasta Shapes You Can Produce

One of the main advantages of a commercial pasta extruder is the ability to produce multiple products by using different dies.

The 200 kg/hr pasta plant can be configured for products such as Penne, Fusilli, Macaroni, Elbow Pasta, Shell Pasta, Spaghetti and other customized pasta shapes.

This allows one manufacturer to build multiple SKUs and serve different markets using the same production setup.

Why Choose a 200 Kg/Hr Pasta Plant?

This capacity is suitable for businesses that need more output than a small pasta machine but still want a manageable commercial production setup.

The plant is designed with focus on high productivity, easy operation, efficient material handling, consistent pasta production and low maintenance requirements.

Its modular production process also makes it easier to understand each manufacturing stage, from raw material feeding to final drying.

SS304 Food-Contact Construction

Food processing equipment requires proper hygiene and easy cleaning.

The pasta plant can be manufactured with SS304 stainless steel for relevant food-contact parts, helping provide a hygienic and durable production environment.

Stainless steel construction also makes routine cleaning and maintenance easier for commercial food manufacturers.

Who Can Use This Pasta Manufacturing Plant?

The 200 kg/hr pasta production line is suitable for pasta manufacturers, food processing companies, FMCG businesses, private-label food manufacturers, distributors planning their own production, existing food factories expanding capacity and entrepreneurs setting up a commercial pasta manufacturing business.

It can be used for supplying pasta to retail markets, wholesalers, supermarkets, distributors, hotels, restaurants and institutional buyers.

Why Choose Khan Engineering?

Khan Engineering provides commercial food processing machinery and complete pasta manufacturing solutions for customers across India.

Instead of supplying only a standalone pasta extruder, we can help customers select a complete production setup based on required capacity, pasta type and manufacturing requirements.

Our focus is on practical machine design, quality construction, easy operation and reliable after-sales support.

Key Benefits

200 Kg/Hr Production Capacity
Suitable for commercial pasta manufacturing.

Multiple Pasta Shapes
Produce different products by changing dies and inserts.

Complete Production Solution
Equipment is available for feeding, mixing, extrusion, conveying, tray handling and drying.

Easy Operation
Centralized controls help operators manage the production process.

Low Maintenance Design
Built for regular commercial production and easier routine maintenance.

PAN India Service Support
Support is available for customers across India.

Export Solutions
Machines can also be supplied for international pasta manufacturing projects.

200 Kg/Hr Pasta Making Machine Price in India

The price of a 200 kg/hr pasta making plant in India depends on the final machine configuration.

Factors such as the number of pasta dies, dryer capacity, automation level, electrical specifications, additional equipment and customization can affect the total project cost.

For the latest price, machine specifications and installation requirements, contact Khan Engineering with your required pasta type and production capacity.

Frequently Asked Questions

What is the production capacity of this pasta plant?

The rated production capacity is up to 200 kg per hour. Actual output can vary depending on pasta shape, raw material, recipe and operating conditions.

Can this machine make different pasta shapes?

Yes. Different dies and inserts can be used to produce various pasta shapes such as penne, fusilli, macaroni, elbow, shell and other shapes.

Does the plant include a pasta dryer?

Yes, a batch pasta drying system can be included as part of the complete production setup.

What happens after pasta comes out of the extruder?

Fresh pasta moves through the conveyor system and is arranged on wooden trays. The trays are loaded into trolleys and transferred to the batch dryer for controlled drying.

Is this machine suitable for starting a pasta business in India?

Yes. A 200 kg/hr plant can be suitable for businesses planning commercial-scale pasta manufacturing. The right capacity should be selected according to your expected sales, working hours, investment and target market.

Can I manufacture multiple products with one plant?

Yes. With suitable dies and production settings, the same plant can be used for several pasta shapes.

Is installation and support available in India?

Khan Engineering provides machinery and service support for customers across India. Confirm installation, training and service terms when requesting your quotation.

Can the plant be customized?

Yes. Configuration can be selected according to production capacity, required pasta products and other project requirements.

Get a Quote for 200 Kg/Hr Pasta Manufacturing Plant

Planning to start a new pasta manufacturing business or increase your existing production capacity?

Contact Khan Engineering for information about the 200 Kg/Hr Pasta Manufacturing Full Plant, machine specifications, plant configuration, pricing and project requirements.
